Note:
1.The maximum working air pressure:4.5Mpa,hydraulic pressure:6.8Mpa;
2.Suitable medium:R22、R502、R407c、R410a、R134a、R404a、R600a etc.refrigerants andother refrigerating oil;
3.Suitable temperature:-40°~140°4.The valve series are on the CE and UL list: CE1282
| Model | “□” mm × mm |
Rotalock Connection |
ODS mm inch. |
I mm |
H mm |
J mm |
L mm |
|
| RV01 | □20 | 3/4"-16UNF SW22 |
6 | —— | 8 | 20 | 32.5 | 104 |
| RV02 | —— | 1/4" | ||||||
| RV03 | 10 | —— | 34.5 | 106 | ||||
| RV04 | —— | 3/8" | ||||||
| RV05 | 12 | —— | ||||||
| RV06 | —— | 1/2" | ||||||
| RV07 | □20 | 1"-14UNF SW30 |
6 | —— | 12 | 22 | 32.5 | 104 |
| RV08 | —— | 1/4" | ||||||
| RV09 | 10 | —— | 34.5 | 106 | ||||
| RV10 | —— | 3/8" | ||||||
| RV11 | 12 | —— | ||||||
| RV12 | —— | 1/2" | ||||||
| RV13 | 16 | 5/8" | ||||||
| RV14 | 19 | —— | 37.5 | 109 | ||||
| RV15 | —— | 3/4" | ||||||
| RV16 | □22 | 1-1/4"-12UNF SW36 |
12 | —— | 13.5 | 2 2 | 34 | 107 |
| RV17 | —— | 1/2" | ||||||
| RV18 | 16 | 5/8" | 36 | 109 | ||||
| RV19 | 19 | —— | 39 | 112 | ||||
| RV20 | —— | 3/4" | ||||||
| RV21 | □30 | 19 | —— | 19 | 28 | 49.5 | 142 | |
| RV22 | —— | 3/4" | ||||||
| RV23 | 22 | 7/8" | ||||||
| RV24 | 28 | —— | 52.5 | 145 | ||||
| RV25 | —— | 1-1/8 | ||||||
| RV26 | 1-3/4"-12UNF SW50 |
19 | —— | 49.5 | 142 | |||
| RV27 | —— | 3/4" | ||||||
| RV28 | 22 | 7/8" | ||||||
| RV29 | 28 | —— | 52.5 | 145 | ||||
| RV30 | —— | 1-1/8" | ||||||
| RV31 | □36 | 28 | —— | 27 | 31 | 59 | 185 | |
| RV32 | —— | 1-1/8" | ||||||
| RV33 | 35 | 1-3/8" | 61 | 187 | ||||
| RV34 | 42 | —— | 65 | 191 | ||||
| RV35 | —— | 1-5/8" | ||||||
| RV36 | □50 | 2-1/4"-12UNF SW65 |
35 | 1-3/8" | 35 | 43 | 72.5 | 201 |
| RV37 | 42 | —— | 74.5 | 203 | ||||
| RV38 | —— | 1-5/8" | ||||||
| RV39 | 54 | 2-1/8" | 76.5 | 205 | ||||
Ningbo Ouyu Import & Export Co., Ltd. is the exporting branch of Briliant Refrigeration Equipment Co., Ltd. It is a manufacturer and factory specializing in the research, development, and design of large-scale refrigeration equipment, with more than 100 talented employees, including masters, researchers, engineering, and technical engineers.
As a professional OEM/ODM/OBM Welding Rotary Lock Joint Valve suppliers and Welding Rotary Lock Joint Valve company with more than 30 years, Ouyu has multiple modern industrial factories equipped with advanced production and processing equipment and complete manufacturing processes. We sell various brands of compressors, condensers, evaporators, condensing units, large and medium-sized parallel units as well as refrigeration accessories with good quality and competitive prices.
We have a complete production line and our products have been awarded ISO9001:2008 quality system certification, CE certification, National Industrial Product Manufacture Licence and Combined Refrigerated Agricultural Machinery Certificate.
