Semi-Hermettc Screw Refrigeration Compressor Supplier

Home / Product / Blait Semi-hermetic Compressor / Semi-Hermettc Screw Refrigeration Compressor

Product Category

Semi-Hermettc Screw Refrigeration Compressor
  • Semi-Hermettc Screw Refrigeration Compressor
  • Semi-Hermettc Screw Refrigeration Compressor
  • Semi-Hermettc Screw Refrigeration Compressor

Semi-Hermettc Screw Refrigeration Compressor

Feature
Small volume, light weight, small vibration, low noise, high effciency and energy saving,environmental protection,security and stability
CONTACT Download Catalog
  • Technical specification
  • About us
  • Get an inquiry
Compressor model Displacement (50Hz) Displacement (60Hz) Discharge Suction Energy regulation  Power supply Maximum power Maximum power Start/block current Weight
m³/h mm (inch) % % A kW A kg
YLG20Z-84 84 101 φ42(15/8") φ54(21/8") 100/90/55 400±10% Δ /ΔΔ 3~/50Hz
460±10%  Δ /ΔΔ 3~/60Hz Part Winding		 48 29 129/210 166
YLG30G-84 84 101 100/90/70 52 33 126/218 170
YLG25Z-100 100 121 100/80/45 52 33 126/218 169
YLG35G-100 100 121 100/85/60 58 37.3 153/266 178
YLG30Z-118 118 142 100/75/45 58 37 153/266 174
YLG40G-118 118 142 100/80/55 66 42 182/311 183
YLG40Z-140 140 168 100/75/50 65 40 187/313 234
YLG50G-140 140 168 100/85/60 79 50 206/355 238
YLG50Z-165 165 198 100/75/45 79 50 206/355 238
YLG60G-165 165 198 100/80/55 98 65 267/449 246
YLG60Z-192 192 232 φ54(21/8") φ76(31/8") 100/80/65 98 65 267/449 297
YLG70G-192 192 232 100/75/45 124 75 290/485 305
YLG70Z-220 220 266 100/75/50 124 75 290/485 310
YLG80G-220 220 266 100/75/50 144 85 350/585 314
YLG75Z-250 250 302 100/75/55 144 85 350/585 326
YLG90G-250 250 302 100/60/40 162 92 423/686 336
YLG90Z-315 315 380 φ76(31/8") DN 100 100/75/50 144 88 394/606 550
YLG110G-315 315 380 180 110 520/801 565
YLG110Z-359 359 433 155 96 439/675 560
YLG125G-359 359 433 216 130 612/943 575
YLG125Z-410 410 495 216 130 612/943 575
YLG140G-410 410 495 246 150 665/1023 580
YLG160G-470 470 567 277 162 729/1144 585
YLG160Z-535 535 640 274 175 729/1114 680
YLG180G-535 535 640 330 181 757/1181 585
