Secop Compressor Series
  • Secop Compressor Series
  • Secop Compressor Series

Secop Compressor Series

Feature

Products Characteristics

Adopt Tecumseh hermetic piston compressor.

Wide applications, adapt L/M/H BP different working conditions

Compact structure small and flexible beautiful appearance, stable andreliable quality.

Adopt famous brand and high quality refrigeration accessories

Can be used in refrigerator freezer



Confiquration

Standard configuration: Compressor, condenser, fan motor, liquid receiverfilter drier.

Selection accessories: Oil separator, pressure controller, H/L P oil gauge.suction accumulator, sight glass.



  • Technical specification
  • About us
  • Get an inquiry

Model

Compressor

Condenser

S(Inch)

D(Inch)

Overall Dimension L*W*H(mm)

Model

HP

Fan Diameter (mm)

Air Flow (m3/h)

Fan voltage

Power of Fan (W)

Poles

KW

UCSP0.25L

SC10CL

0.25

200

530

220V/1PH/50Hz

43

4

0.9

8.2

9.5

460X360X250

UCSP0.33L

SC12CL

0.33

250

730

220V/1PH/50Hz

50

4

13

10.2

9.5

460X400X300

UCSP0.5L

SC15CL

0.5

300

1664

220V/1PH/50Hz

85

4

1.9

10.2

9.5

460X460X350

UCSP0.75L

SC18CL

0.75

300

1664

220V/1PH/50Hz

85

4

2.5

10.2

9.5

460X460X350

UCSP1L

SC21CL

1

350

2270

220V/1PH/50Hz

129

4

2.7

10.2

9.5

520X500X460

Condensingtemperature 50°C,subcooling 0K

Model

Compressor

Coolingcapacity(W)

Refrigerant

Temperature/°C



Evaporating Temperature

Model

HP

-10ºC

-15ºC

-20ºC

-25ºC

UCSP0.25L

SC10CL

0.25

690

532

400

290

R404A

-25ºC+5ºC

UCSP0.33L

SC12CL

0.33

904

697

524

380

UCSP0.5L

SC15CL

0.5

1028

792

596

432

UCSP0.75L

SC18CL

0.75

1190

917

689

500

UCSP1L

SC21CL

1

1410

1087

817

593
