Copeland ZR Series R407c Scroll Compressor for Air Conditioner
  • Copeland ZR Series R407c Scroll Compressor for Air Conditioner

Copeland ZR Series R407c Scroll Compressor for Air Conditioner

Feature
The axial and radial flexibility technology of the copeland scroll ensures the compressor
Excellent reliability and efficiency
Broad product capacity range
Lower oil circulation rate
Superior resistance to liquid hammer
Lower noise and vibration levels
Lower LCCP (Life Cycle Climate Performance)
Dual machine parallel and triple machine parallel, with excellent seasonal energy efficiency
  • Technical specification
  • About us
  • Get an inquiry
Typical Model Nominal Power (HP) Nominal Capacity Input power (W) Current        (A) Displ  (cm3/rev) Weight   (kg) Height   (mm) Noise   (dBA)
(W) (Btu/h)
ZR24K3E-TFD 2 5,900 20,119 1,920 4.3 5.92 25.0  383 69.0
ZR36K3E-TFD 3 8,900 30,349 2,680 5.7 8.61 28.0  406 71.0
ZR42K3E-TFD 3.5 10,250 34,952 3,100 7.1 9.94 28.0  406 69.0
ZR47K3E-TFD 3.92 11,550 39,385 3,430 7.2 11.16 30.0  436 71.0
ZR61KCE-TFD 5.1 14,000 47,600 4,460 8.4 3.14 28.0  436 71.0
ZR68KCE-TFD 5.7 14,800 54,000 5,100 8.9 3.11 39.0  436 72.0
ZR72KCE-TFD 6 16,600 56,500 5,150 9.1 3.22 57.2  457 72.0
ZR81KCE-TFD 6.8 18,600 63,500 5,990 10.9 3.17 39.0  457 72.0
ZR94KCE-TFD 7.8 23,000 78,600 6,950 12.9 3.34 57.2  462 74.0
ZR108KCE-TFD 9 28,800 88,100 7,580 13.8 3.4 59.9  497 74.0
ZR125KCE-TFD 10.4 30,000 103,000 8,950 16 3.4 61.2  552 74.0
ZR144KCE-TFD 12 34,500 118,000 10,150 17.7 3.4 61.2  552 75.0
ZR160KCE-TFD 13.3 37,500 128,000 11,450 20.5 3.28 64.9  552 78.0
ZR190KCE-TFD 15.8 44,000 150,000 13,650 26.5 3.22 66.2  552 82.0
ZR250KCE-TWD 20.8 58,500 200,000 18,000 30.1 3.25 139.3  552 83.0
ZR310KCE-TWD 25.8 72,500 248,000 22,300 37.9 3.25 160.1  552 85.0
ZR380KCE-TWD 31.7 91,500 313,000 26,700 45.5 3.43 176.9  552 88.0
